14Kpa high pressure dc brushless mini electric air blower centrifugal fan
WS9290B-24-220-X300
A powerful and efficient mini air blower that can generate up to 14Kpa of high pressure air flow. Perfect for a range of applications, from cooling electronic devices to cleaning hard-to-reach areas.
Quantity
| Brand name: Wonsmart Blower | Certification: CE, RoHS, ETL,REACH |
| 14Kpa high pressure dc brushless mini electric air blower | Warranty: 1 Year |
| Blower type: air blower centrifugal fan | After-sales Service Provided: Online support |
| Voltage: 24 vdc | Life time(MTTF): >20,000hours (under 25 degree C) |
| Bearing: NMB ball bearing | Weight: 490 grams |
| Applicable Industries: Manufacturing Plant | Unit size: D92mm *H90mm |
| Electric Current Type: DC | Motor type:Three Phase DC Brushless Motor |
| Place of Origin:Zhejiang, China | Static pressure: 6.8kPa |
 |  |
WS9290B-24-220-X300 blower can reach maximum55m3/h airflow at 0 kpa pressure and maximum14kpa static pressure.It has maximum output air power when this blower run at 3kPa resistance if we set 100% PWM, It has maximum efficiency when this blower run at 14kPa resistance if we set 100% PWM.Other load point performance refer to below P-Q curve:
(1)WS9290B-24-220-X300 blower is with brushless motors and NMB ball bearings inside which indicates very long life time; MTTF of this blower can reach more than 20,000hours at 20degree C environmental temperature.
(2)14Kpa high pressure dc brushless mini electric air blower centrifugal fan needs no maintence;
(3)This air blower centrifugal fan drived by a brushless motor controller have many different control functions such as speed regulation,speed pulse output,fast acceleration, brake etc.it can be controlled by intelligent machine and equipment easily.
(4) Drived by brushless motor driver the blower will have over current, under/over voltage,stall protections.
The 14Kpa High Pressure DC Brushless Mini Electric Air Blower Centrifugal Fan is a must-have for any industrial or commercial setting. With its powerful motor, it delivers optimal performance for a wide range of air-moving applications. Plus, with its brushless design, it requires less maintenance and is more energy-efficient than traditional brush motors. Its compact size makes it ideal for tight spaces and its quiet operation ensures minimal disruption. From ventilation systems to cooling applications, this centrifugal fan is the solution for all your air-moving needs.
